Narrowband Limiters Series LIM 12/335

SUPER HETERODYNE WIDEBAND RECEIVER MODEL WBR-0518-MOD

                                                                                                                                     Special Order Product Consult Factory Before Ordering

Dimensions are stated in mm (inches). Tolerances, unless
otherwise indicated: .XX ±.02; .XXX ±.005

PERFORMANCE CHARACTERISTICS

Model LIM-12-VHP LIM-1214-VHP LIM-335-VHP
Frequency Range (GHz) 1.0 – 2.0 1.2 – 1.4 3.1 – 3.5
Insertion Loss, dB max 0.8  0.7  1.0
V.S.W.R, max 1.5:1  1.3:1  1.3:1
Input Power, Watts, max CW 40  30  25
Peak 400  300  250
Pulse Width, μSec. max 10  20  50
Duty Cycle, % max 10  10  10
Flat Leakage, mWatts max 100  100  32
Recovery Time, nSec max 400  400  350
Operating Temperature Range, °C max -30 to +75  -30 to +75  -30 to +75
Package 200/2-79 2002/2-10  200/2-79
Connectors Input SMA (Female)
Output SMA (Female)



Broadband Limiters Series LIM 118/218

Package

Narrowband Limiters Series LIM 12/335

Dimensions are stated in mm. Tolerances, unless
otherwise indicated: .XX ±.02; .XXX ±.005
